·DTL、STJ型上運固定帶式輸送機 Upwards conveying b

DTL、STJ型上運固定帶式輸送機 Upwards conveying belt conveyor型號規格 Model運量 capa.運距 Max length帶寬 Belt width帶速 Speed傾角 Upper slope電機功率 Power傳動滾筒直徑 Drum Dia.托輥直徑 Roller Dia.整機質量 Weightt/hmmmm/s()kwmmmmt上運固定帶式輸送機Upwar

DTL、STJ型上運固定帶式輸送機 Upwards conveying belt conveyor

型號規格 Model	運量 capa.	運距 Max length	帶寬 Belt width	帶速 Speed	傾角 Upper slope	電機功率 Power	傳動滾筒直徑 Drum Dia.	托輥直徑 Roller Dia.	整機質量 Weight
型號規格 Model	t/h	m	mm	m/s	(°)	kw	mm	mm	t
上運固定帶式輸送機Upwards conveying belt conveyor
STJ650/75S	200	315	650	1.6	16	75	500	89	31.09
DTL80/20/250S	200	900	800	2	17	250	1000	89	83.19
DTL80/25/125S	250	410	800	2	10	125	630	108	73.44
DTL80/30/2×250S	300	1000	800	2.5	17-12	2×250	1250	108	113.87
STJ800/160S	350	850	800	2	6.5	160	630	108	93.50
DTL80/35/2×220	400	750	800	2	16	2×220	1000	108	126.31
DTL80/40/2×220	300	1050	800	2	14	2×220	1000	108	181.5
DTL100/30/2×160S	320	1000	1000	2.5	8	2×160	800	108
DTL100/32/2×220	350	1030	1000	2	16	2×220	1000	133	200.94
STJ1000/2×125S	350	500	1000	2	11.5	2×125	800	108
DTL100/35/2×132S	350	1250	1000	2	13	2×132	800	108	41.74
DTL100/40/2×200S	400	1260	1000	2	14	2×200	1000	133	139.35
DTL100/45×280	450	468	1000	2	5-16	280	1250	108	103.14
DTL100/50/2×355S	500	1100	1000	2.5	16	2×355	1400	108	250.99
DTL100/50/2×110	500	516	1000	2.5	8	2×110	1024	108	75.95
DTL100/60×200	600	1600	1000	2	14	200	630	108	95.91
DTL100/63/2×200	630	1000	1000	2	8	2×220	1000	133	124.32
DTL100/70/2×160S	700	300	1000	2.5	16	2×160	800	108	57..99
STJ1000/2×220S	750	400	1000	2.5	14	2×220	1280	108	77.61
STJ1000/160S(A)	800	700	1000	2.5	3	160	630	108	65.56
STJ1000/2×200S	950	690	1000	3.15	8	2×200	800	133	99.91
DTL100/100/3×250S	1000	1500	1000	3.15	0-12	3×250	1030	133	277.5
DTL100/100/2×250S	1000	380	1000	3.15	16	2×250	1000	133	65.15
DTL100/80/200	800	450	1000	2.5	7	200	800	108	54.31
DTL120/70/2×160S	700	490	1200	2	14	2×220	1000	108
STJ1200/2×160S	800	360	1200	2.5	15	2×160	800	108	67.2
DTL120/50/2×160	500	400	1200	2.5	16	160	500	108	49.97
DTL120/100/2×250	1000	1498	1200	2.5	14	2×250	1250	133	227.18
DTL120/120/3×315	200	1650	1200	2.5	15	315	1250	159	148.97
DTL120/150/3×200	500	1500	1200	3.15	14	3×200	800	133	184.55
DTL120/180/250	1800	955	1200	3.5	6	2×250	1250	133	164.01
DTL140/120/90	1200	85	1400	3.15	0-3	90	800	159	37.67
DTL140/204/400S	2040	182	1400	3.8	17	400	1250	159	74.94
DTL160/220/560	2200	264	1600	2.5	3	560	1000	159
DTL140/280/710	2800	186	1400	5	6	710	1286	159	38.12
DTL160/250/280	2500	77	1600	3.15	5	280	1000	159	38
DTL160/350/710	3500	195	1600	4.5	4	710	1125	159	80.36
DTL160/160/330/2×315S	3300	269	1600	4.5	9	2×315	1000	159	144.05
DTL180/3000/2×450	3000	348	1800	3.15	0-11	2×450	1036	159	131.5
