DXK、DTL、STJ型固定帶式輸送機 Fixed belt conveyor
| 型號規格 Model | 運量 capa. | 運距 Max length | 帶寬 Belt width | 帶速 Speed | 傾角 Upper slope | 電機功率 Power | 傳動滾筒直徑 Drum Dia. | 托輥直徑 Roller Dia. | 整機質量 Weight |
| t/h | m | mm | m/s | (°) | kw | mm | mm | t | |
| 主井、大巷固定帶式輸送機Fixed belt conveyor | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| DXK800/2×110S | 186 | 878 | 800 | 2 | 15 | 2×110 | 800 | 89 | 82.72 |
| DTL100/20×90S | 200 | 550 | 1000 | 1.6 | 11 | 2×90 | 630 | 108 | 48.15 |
| DXK1000/2×220 | 400 | 606 | 1000 | 2 | 15 | 2×220 | 1000 | 108 | 151.56 |
| DXK1000/220 | 450 | 460 | 1000 | 2 | 16 | 220 | 1000 | 108 | 89.76 |
| DXK1000/132 | 500 | 630 | 1000 | 2.5 | 132 | 1000 | 108 | 80.38 | |
| DTL100/2/50/2×280S | 500 | 1050 | 1000 | 2.5 | 13 | 80 | 1250 | 108 | 47.89 |
| DXK1000/2×315S | 560 | 770 | 1000 | 2.5 | 17 | 2×315 | 1400 | 108 | 198.45 |
| DTL100/80/2×160S | 800 | 1000 | 1000 | 2.5 | 2×160 | 630 | 108 | ||
| DXK1000/250 | 930 | 350 | 1000 | 3.15 | 15 | 250 | 1286 | 133 | 25.54 |
| 主井、大巷固定帶式輸送機Fixed belt conveyor | |||||||||
| DXK1000/2×132 | 1000 | 150 | 1000 | 2 | 16 | 2×132 | 1000 | 108 | 41.47 |
| STJ1000/2×220 | 1000 | 2060 | 1000 | 3.15 | 2×220 | 1000 | 133 | ||
| DTL100/100/2×315 | 1000 | 1120 | 1000 | 3.15 | 5 | 2×315 | 1250 | 133 | 184.63 |
| DXK1200/3×250 | 800 | 845 | 1200 | 2.5 | 13 | 3×250 | 1250 | 108 | 237.89 |
| DXK1200/2×400 | 1000 | 1987 | 1200 | 3.4 | 0-12 | 2×400 | 1286 | 133 | 330.39 |
| DXK1200/200 | 1000 | 406 | 1200 | 2.5 | -13 | 200 | 800 | 133 | 94.52 |
| DTL120/100/200 | 1000 | 614 | 1200 | 2.5 | 200 | 1000 | 108 | 101.32 | |
| DXK1200/2×630 | 1100 | 1086 | 1200 | 3.4 | 14 | 2×630 | 1400 | 133 | 389.55 |
| STJ1200/2×250 | 1200 | 850 | 1200 | 2.5 | 2×250 | 800 | 133 | 287.33 | |
| STJ1200/2×200 | 1200 | 1500 | 1200 | 2.5 | 2×200 | 800 | 133 | 195.71 | |
| DTL120/180G4×200 | 1800 | 2000 | 1200 | 3.3 | 4×200 | 800 | 133 | 254.47 | |
| DTL140/250/2×355 | 2500 | 1280 | 1400 | 3.5 | 2×355 | 800 | 159 | 289.42 | |
| DTL160/330/3×1600 | 3300 | 1780 | 1600 | 4.5 | 12 | 3×1600 | 2040 | 159 | 431.66 |
| 轉彎固定帶式輸送機Curred belt conveyor | |||||||||
| DTL100/50/110 | 500 | 660 | 1000 | 2.5 | ≤10 | 110 | 630 | 108 | 52.14 |
| DTL120/80/315 | 800 | 1160 | 1200 | 2.5 | ≤10 | 315 | 800 | 133 | 140.58 |
