一、產品簡介
I. Product Description

高溫高壓無氰解吸電解裝置是采用新技術、新工藝，應用于黃金生產中處理載金炭的新型、高效、專利產品。該裝置對于黃金礦山炭漿廠和堆浸廠產出的載金炭都能很好的進行解吸，產出黃金。該裝置自動化程度高，技術指標先進，設備質量好，操作簡單易行，設備運行特別穩定可靠、安全。產品已銷售20多個省、并出口俄羅斯、緬甸、蒙古國、朝鮮。

The high-temperature and high-pressure cyanide free electrolysis device integrated with new technique and technology is a new style high-efficiency patented product that is designed for processing of gold carrier carbon during gold production. This device can effectively process the gold carrier carbon from carbon pulp plant and leaching plant of gold mine. Additionally, this equipment is highly automatic with advanced technical parameters, high quality and is easy to operate, stable, reliable and safe. This product has been sold to more than 20 provinces and exported to Russia, Myanmar, Mongolia and North Korea.

二、產品優點：
II. Benefits:

1、解吸率高
1. High desorption rate

在高溫（150℃ ）、高壓（0.45～0.55MPa ）、無氰解吸藥劑的條件下解吸，解吸率高（98%～99.8%）。93%以上的我廠用戶貧炭品位在50克/噸以下。
The desorption is performed in the condition at high temperature (150℃) and high pressure (0.45～0.55MPa) with cyanide free desorption agent, so the desorption rate is extremely high (98%~99.8%). For the level higher than 93%, the depleted carbon grade for our customer is lower than 50g/t.

2、提高吸附率
2. Improved adsorption rate

加到吸附工藝中經過解吸活化的低品位貧炭，能明顯地降低尾液品位，能提高吸附率0.5%～7% 。創造出顯著的經濟效益。
The desorbed and activated low-grade deleted carbon that is added to absorption process can significantly reduce the tail fluid grade and may increase the absorption rate by 0.5%～7%, creating significant economic benefits.

3、生產成本低
3. Low production cost

處理每噸載金炭的直接生產成本為290～690 元，比其它解吸電解設備能夠降低生產成本65%～85%
The direct production cost for processing each ton of gold carrier carbon is 290～690 Yuan, which is 65%-85% lower than that of other desorption & electrolysis devices.

4、生產能力大
4. High productivity

日處理0.3～10 噸載金炭。
0.3～10 tons of gold carrier carbon can be processed per day.

5、無氰解吸
5. Cyanide desorption

發明了新型安全無毒的組合解吸藥劑，對任何解吸的載金炭，都必須可取得理想的解吸效果，屬于經色環保工藝。而且此工藝的解吸液能循環利用數十次，節省藥劑和水。只單獨采用NaOH 做為解吸藥劑，對大部分礦山的載金炭解吸效果是不理想的。
The newly invented non-toxic desorption agent combination integrated with environmental protection technology has ideal desorption effect on any gold carrier gold. In addition, desorption fluid of this technology can be recycled for dozens of times for conservation of agent and water. Desorption agent NaOH solely used does not have ideal desorption effect on gold carrier carbon of most mines.

6、立式承壓平衡電解槽
6. Vertical pressure balance electrolytic bath

我廠發明的立式承壓平衡電解槽不但電解率高：≥99.99% ；而且使解吸電解工藝流程簡明實用，解吸、電解效果好。一個月只打開1～3次的電解槽，采用氣動扳手上卸螺栓，方便，安全可靠；并且此立式電解槽不泄漏含金氣體。立式承壓平衡電解槽具有自動排放金泥系統，杜絕人工操作造成的金泥損失，丟失。
The vertical pressure balance electrolytic bath developed by our factory features a high electrolysis rate (≥99.99%). Additionally, desorption electrolytic process is clear and practical, contributing to outstanding desorption and electrolysis effect. The electrolytic bath needs only to be opened for 1-3 times per month; bolts are tightened and unscrewed with pneumatic wrench for the purpose of convenience, safety and reliability; also, no gold-bearing gas will leak from this vertical electrolytic bath which is also equipped with an automatic gold dust discharge system that can prevent the dust loss caused by manual operation.

7、貧炭不需要火法熱再生
7. Depleted carbon needs no pyrogenic heat generation

無毒的組合解吸藥劑含有炭活化劑，活化劑對炭起到再生作用。采用此解吸電解工藝，貧炭不需要火法熱再生，杜絕了貧炭火法熱再生造成的炭損失和金損失，節省了炭火法熱再生成本和炭火法熱再生設備投資。
Non-toxic desorption agent combination contains carbon activator that performs carbon generation. With this desorption electrolysis technology, depleted carbon needs no pyrogenic heat generation. In this way, the carbon and gold loss caused by heat generation is avoidable, and the cost of process and equipment thereof will be reduced.

8、設備回報率高
8. High equipment return rate

我廠的設備回報率高、經濟效益顯著。使90%的用戶在一年內收回了設備投資；并且在應用后一個月內收回設備投資的礦山2家，在3個月內收回設備投資的礦山13家。
Our equipment enjoys high return rate and will produce significant economic benefit, enabling 90% of the users to recover the investment in equipment within one year. For example, two mines have recovered the investment in equipment within one month, and 13 within three months.

9、多臺大型解吸電解裝置（≥2000 公斤/批）在生產中取得了效果良好的成功應用。
9. Several large desorption electrolysis installations (≥2000kg/batch) have been successfully operating and attained perfect results during the production.

10、優異的設備質量
10. Outstanding equipment quality

用戶先后選用我廠三套解吸電解設備的共有四家，選用二套的用戶七家；陜西省內炭漿工藝的黃金礦山選用我廠設備，至今已達十一套。
Among the users, four have purchased three sets of desorption electrolysis equipment from our factory; gold mines adopting CIP technology in Shaanxi Province have purchased 11 sets from our factory.

11、高溫高壓解吸電解設備，取代了多臺其它廠家生產的高溫高壓解吸電解設備。
11. High-temperature and high-pressure desorption electrolysis equipment manufactured by our factory have replaced a number of high-temperature and high-pressure desorption electrolysis equipment produced by other factories.

12、采用特種無損自動方式輸送炭，在炭運輸過程中不產生粉炭，不造成炭損失和金損失。
12. Since the carbon is conveyed in a special non-destructive auto mode, no carbon powder will occur during carbon conveyance, thus no carbon and gold loss will occur.

13、貧炭品位低，炭損又低，能顯著降低粉炭、碎炭造成的金損失；能夠降低選礦生產流程中的黃金積壓量。
13. The depleted carbon with low grade and low loss will significantly reduce the gold loss caused by carbon powder and broken carbon, and thus reduce the gold backlog during beneficiation.

14、自動化程度高，工人勞動強度低；在無氰環境內工作，工作環境好。
14. High degree of automation and low labor intensity; cyanide-free environment.
高溫高壓無氰解吸電解裝置規格型號 Model and specification of high-temperature and high-pressure cyanide-free desorption electrolysis equipment

型號	每批生產能力 公斤載金炭/批	每日生產能力 公斤載金炭/批
JCC - 500	500	500-750
JCC- 300	300	300-450

Model	Productivity/batch Gold carrier carbon kg/batch	Daily production capacity Gold carrier carbon kg/batch
JCC - 500	500	500-750
JCC- 300	300	300-450

除以上規格外，可以根據用戶需要設計制造特殊規格的高溫高壓無氰解吸電解裝置。例如：雙解吸柱、雙電解槽、不同加熱方式的高溫高壓無氰解吸電解裝置。

We are able to design and produce high-temperature and high-pressure cyanide-free desorption electrolysis equipment according to customers’ special requirements, for example, double-column and double electrolytic bath high-temperature and high-pressure cyanide-free desorption electrolysis equipment adopting different heating methods.
